Usage: Automatic bottle cap hot stamping machine is designed for fully automatic rolling foil stamping on those round and irregular bottle caps. It is ideal for those medium and lager enterprise in the field of cosmetic bottles and caps manufacturer or printing industry.
Specification:
HC-HA-CapT Automatic cap hot stamp machine
Specification:
1: Total consume Wattage: 2.2KW;
2. Stamping temperature Range: 20-300°C;
3. Compress air Pressure: 0.6MPA;
4. Products Diameter:DIA:15-34MM L:25-60MM
5. Max stamping Speed: 4200pcs/hr
6. Outer dimension: 210*140*230CM
7. Net weight : 800KG
Features:
1. Silicon Rolling foil stamping system for assuring perfect stamping quality.
2: Fully automatic loading and feeding system for mostly degree of saving labor cost and most efficiency.
3: PLC control system, with no caps no print, counting, code setting, maintenance, temperature control, automatic alarming system etc.
4: International Famous pneumatic parts included Japan SMC cylinder, valves, Germany OMERON sensors etc.
5: Japan and Taiwan famous brand DEFOILER motor, STEPPER MOTOR, vacuum pump motor etc.
6: SCHNEIDER OR PANOSONIC key electrical components
7. Safe protection device installed.
8: Free technical and operation Training available.
Power Supply: 220V/50HZ
Standard Certificate: ISO9001-2000
Country of Origin: Guangdong, China
Payment Terms: T.T, PayPal, Western Union or L/C
Lead time: Within 5 days when get buyer’s payment or deposit
Shippment: By sea
Guaranty: one year
Packing: by wooden cases
Packing size: 2150X1450X2350mm
Packing volume: 7.3CBM
Gross weight: 900KG
Machine Fittings for free:
1) 1 set Tool box;
2) Operation instruction in English
Please click here to see the video http://youtu.be/bht5x7yGTh4
